Plastic Processed:
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP
Condition:
New
Style:
Horizontal
Distance between Tie Bars(Width)(mm):
580mm
Distance between Tie Bars(Height)(mm):
580mm
Mold Height(mm):
220 - 600 mm
Ejector Stroke(mm):
160 mm
Ejector Force(kN):
77 kN
Theoretical Shot Volume(cm³):
595 cm³
Injection Rate (g/s):
212 g/s
Machine Type:
Hydraulic
Injection Weight (g):
542 g
Screw diameter (mm):
53 mm
Distance between Tie Bars:
580mm*580mm
Weight (KG):
8500
Place of Origin:
Zhejiang, China
Open Stroke(mm):
560 mm
Model Number:
HMD268M8/M8-S
Μάρκα:
HMD
Power (kW):
45 kW
Warranty:
1 Year
Key Selling Points:
Multifunctional
Applicable Industries:
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops
Showroom Location:
Turkey, Indonesia, Mexico, Russia, Malaysia
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
PLC
Screw stroke:
270mm
Screw speed(stepless):
0~180r/min
Platen size:
850mm*850mm
Max.daylight:
1160mm
Hydraulic ejection force:
77KN
Hydraulic system pressure:
17.5MPa
Pump motor:
22/28.7KW
Heating capacity:
18.2KW
Plastic Type:
Thermoplastic
Clamping Force (kN):
2680 kN
After-sales Service Provided:
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
After Warranty Service:
Video technical support, Online support
Local Service Location:
Turkey, Indonesia, Mexico, Russia, Malaysia
